Item No :
JNSG15KHF4815-V1 series;JNSG15KHF4820-V1 seriesOrder(MOQ) :
1Payment :
FOBProduct Origin :
Hefei Anhui ChinaColor :
GreyShipping Port :
Nanjing, Ningbo, Shanghai,Shenzhen,GuangzhouLead Time :
7daysWeight :
100-300kg5-15kW Complete Solar Energy System for Residential
The Solar home battery system includes solar panels, inverters, batteries, and intelligent controllers, all of which have undergone rigorous testing and debugging to ensure stable and reliable system operation.The Home Solar Storage Solutions is easy to install and use. It is not only a system that converts solar energy into electricity, but also a way to protect the environment. It can meet people's demand for a pollution-free, low-carbon and environmentally friendly life.
Smart control by mobile APP/Web
2. The battery and the inverter use BMS communication to monitor the battery SOC at all times to ensure that the SOC is within a reasonable range. When the SOC of each battery group is found to be unbalanced, changing the inverter parameters can automatically balance the battery power
Model
|
JNSG5KHF4810-V1
|
JNSG5KHF4815-V1
|
JNSG5KHF4820-V1
|
PV Input
|
|||
Max.PV input voltage
|
450Vdc
|
450Vdc
|
450Vdc
|
Recommended input power
|
7000W
|
7000W
|
7000W
|
MPPT voltage range
|
120~430Vdc
|
120~430Vdc
|
120~430Vdc
|
Battery
|
|||
Rated voltage
|
48Vdc
|
48Vdc
|
48Vdc
|
Max.charge current
|
80A
|
80A
|
80A
|
Efficiency
|
≥97%
|
≥97%
|
≥97%
|
Type & Rated capacity
|
Gel/lithium & 10kWh
|
Gel/lithium & 15kWh
|
Gel/lithium & 20kWh
|
AC Input、Bypass output
|
|||
Voltage and frequency
|
230Vac±20%,50/60Hz (±3%)
|
230Vac±20%,50/60Hz (±3%)
|
230Vac±20%,50/60Hz (±3%)
|
Max. charge current
|
60A
|
60A
|
60A
|
Switching time
|
≤10ms
|
≤10ms
|
≤10ms
|
Inverter Output
|
|||
Rated output capacitor
|
5000VA
|
5000VA
|
5000VA
|
Rated output power
|
5000W
|
5000W
|
5000W
|
Output voltage
|
220Vac/230Vac
|
220Vac/230Vac
|
220Vac/230Vac
|
Rated frequency
|
50/60Hz (±3%)
|
50/60Hz (±3%)
|
50/60Hz (±3%)
|
Standby loss
|
≤10W
|
≤10W
|
≤10W
|
Max. efficiency
|
93%
|
93%
|
93%
|
Waveform
|
Sine wave
|
Sine wave
|
Sine wave
|
Total harmonic distortion (THD)
|
<3%
|
<3%
|
<3%
|
Overload
|
5s@≥150% load;10s@ 110%~150% load
|
5s@≥150% load;10s@ 110%~150% load
|
5s@≥150% load;10s@ 110%~150% load
|
Others
|
|||
Protecition level
|
IP21
|
IP21
|
IP21
|
Autible noice
|
<60dB
|
<60dB
|
<60dB
|
Cooling method
|
Forced cooling
|
Forced cooling
|
Forced cooling
|
Operate temp.
|
-20~+50℃
|
-20~+50℃
|
-20~+50℃
|
Storage temp.
|
-25~+70℃
|
-25~+70℃
|
-25~+70℃
|
Status indicator
|
LCD+LED
|
LCD+LED
|
LCD+LED
|
Interface
|
RS485/CAN
|
RS485/CAN
|
RS485/CAN
|
Altitude
|
2000m( >2000m derating operate)
|
2000m( >2000m derating operate)
|
2000m( >2000m derating operate)
|
Dimension(W*D*H)
|
674*698*480mm
|
674*895*480mm
|
674*1093*480mm
|
Weight
|
143kg
|
202kg
|
260kg
|
Model |
JNSG10KHF4810-V1
|
JNSG10KHF4815-V1
|
JNSG10KHF4820-V1
|
PV Input | |||
Max.PV input voltage | 450Vdc | 450Vdc | 450Vdc |
Recommended input power | 14000W | 14000W | 14000W |
MPPT voltage range | 120~430Vdc | 120~430Vdc | 120~430Vdc |
Battery | |||
Rated voltage | 48Vdc | 48Vdc | 48Vdc |
Max.charge current | 160A | 16A | 160A |
Efficiency | ≥97% | ≥97% | ≥97% |
Type & Rated capacity | Gel/lithium & 10kWh | Gel/lithium & 15kWh | Gel/lithium & 20kWh |
AC Input、Bypass output | |||
Voltage and frequency | 230Vac±20%,50/60Hz (±3%) | 230Vac±20%,50/60Hz (±3%) | 230Vac±20%,50/60Hz (±3%) |
Max. charge current | 120A | 120A | 120A |
Switching time | ≤10ms | ≤10ms | ≤10ms |
Inverter Output | |||
Rated output capacitor | 10000VA | 10000VA | 10000VA |
Rated output power | 10000W | 10000W | 10000W |
Output voltage | 220Vac/230Vac | 220Vac/230Vac | 220Vac/230Vac |
Rated frequency | 50/60Hz (±3%) | 50/60Hz (±3%) | 50/60Hz (±3%) |
Standby loss | ≤20W | ≤20W | ≤20W |
Max. efficiency | 93% | 93% | 93% |
Waveform | Sine wave | Sine wave | Sine wave |
Total harmonic distortion (THD) | <3% | <3% | <3% |
Overload | 5s@≥150% load;10s@ 110%~150% load | 5s@≥150% load;10s@ 110%~150% load | 5s@≥150% load;10s@ 110%~150% load |
Others | |||
Protecition level | IP21 | IP21 | IP21 |
Autible noice | <60dB | <60dB | <60dB |
Cooling method | Forced cooling | Forced cooling | Forced cooling |
Operate temp. | -20~+50℃ | -20~+50℃ | -20~+50℃ |
Storage temp. | -25~+70℃ | -25~+70℃ | -25~+70℃ |
Status indicator | LCD+LED | LCD+LED | LCD+LED |
Interface | RS485/WIFI | RS485/WIFI | RS485/WIFI |
Altitude | 2000m( >2000m derating operate) | 2000m( >2000m derating operate) | 2000m( >2000m derating operate) |
